Stoppy MBB 219/500 SS – Electro Mechanical Bollard

£5,595.00 INC VAT
(£4,662.50 EXC VAT)

Please enter your postcode to get installation information

All our prices include VAT & Delivery to UK Mainland

Buy more save more

Minimum Qty

Discount

5+

5%

10+

10%

20+

15%

Description

This bollard is designed to work in extreme conditions with all metal parts cataphoresis-treated. The seal integrated into the flange is a new EPDM. These automatic bollards are built for high usage, with an internal oil-bath gear motor.

With a leading reputation in the gate automation industry leaders, all BFT products are built to exceptional standards and designed to be easy to install.

The Stoppy MBB electromechanical bollard has an LED light cap which fits perfectly into the floor flange, when the shaft is lowered. This reduces the risk of debris getting into the casing.

The Stoppy MBB comes in two versions 500 mm or 700 mm in height and 219 mm diameter, all versions are equipped with an LED light crown and are available in two finishes: painted steel coloured RAL 7015 or stainless steel.

This bollard is compatible with the Perseo CBD control panel which can manage up to four bollards in parallel. This unit features a programming menu on the display with an integrated heating element and an incorporated receiver.

  • Bollard comes with two key fob transmitters to operate the bollard
  • Operated by key fob, from your smartphone or via an intercom



Main Features

  • The option of supply as an integrated unit or with outer casing separate from the operator allows the installer to complete digging and preparation for the installation ahead of time.
  • The new square flange allows for perfect architectonic integration and hence better insertion into the full range of urban contexts.
  • The conical stem cap and EPDM flange gasket provide highly effective protection against foreign matter entering between the stem and the outer casing, thus making the unit maintenance free.

Key Data

Finish: Grade 304 Stainess Steel

Shaft diameter (mm): 219

Shaft height (mm): 500

Raising time: 6 seconds

Control unit: PERSEO CBE

Operator type: Electro Mechanical. Mitto RCB 02 Key Fob included x 2. Operated by key fob, from your smartphone or via an intercom

Type of limit switch: reed magnetic sensor

Protection rating: IP67

Impact resistance: 8,000J

Breaking resistance: 150,000J

Lock: Electric break

Manual operation: Reversible with no power

Frequency of use: up to 1,500 operations a day

Ambient conditions: -25 degrees +60 degrees

Manufacturing Standards: BS1440 and BS EN ISO 1461 (2009)

LED Light Crown available

In the event of a power cut, the bollard with lower automatically

Warranty: 12 months
